Modified LSA Accessory Drive System, w/o AC

$1,298.05 $1,246.13
(You save $51.92)

GM

Modified LSA Accessory Drive System, w/o AC

$1,298.05 $1,246.13
(You save $51.92)
SKU:
19303242
Weight:
28.89 LBS
Availability:
Y
Shipping:
Calculated at checkout
Quantity:
Share

Product Description

19303242
Modified LSA Accessory Drive System, w/o AC Similar to LSA Accessory Drive Kit P/N 19243525, but designed for retro-fit applications with a relocated alternator and power steering pump to provide chassis clearance in older vehicles

  • Includes power steering pump and two remote-mount reservoirs; builder to use the reservoir that provides the best fit for the application
  • Requires fabrication of reservoir mounting bracket
  • Requires reservoir-to-pump hose
  • Can be used with either LSA AC add-on or Corvette AC add-on kit

The system includes:
Part # Qty Description
12616673 1 Belt-w/pmp & Gen & P/S Pump
12628025 1 Tensioner ASM-DRV Belt
11571051 2 Bolt/Screw-DRV Belt Tensr
12568996 1 Pulley ASM-Belt Idler
12636227 1 Belt-SPCHG
12622452 1 Tensioner ASM-SPCHG Belt
11588753 1 Bolt/Screw-SPCHG Belt Tensr
12606500 1 Bracket-SPCHG Belt Tensr
11588742 1 Bolt/Screw-SPCHG Belt Tensr Brkt
11588749 2 Bolt/Screw-SPCHG Belt Tensr Brkt
12606031 1 Pulley ASM-SPCHG Belt Idler
12606032 1 Pulley ASM-SPCHG Belt Idler
11518630 2 Bolt/Screw Belt Idler Pul
12606501 1 Bracket-SPCHG Belt Idler Pul
11589311 1 Bolt/Screw-SPCHG Belt Idler Pul Brkt
11610074 3 Bolt/Screw-SPCHG Belt Idler Pul Brkt
12578067 1 Bracket-Gen/P/STG/ Pump
11516357 3 Bolt/Screw-Gen Brkt
12555693 1 Brace-P/S Pump
11588745 1 Bolt/Screw
24503609 2 Bolt/Screw
11515758 2 Bolt/Screw
11516697 2 Bolt/Screw
12568997 1 Pulley-P/S Pump
25960709 1 P/S Pump
25888970 1 Generator
22768353 1 P/S Pump Reservoir
26046502 1 P/S Pump Reservoir
10317982 1 Cap - P/S Reservoir
12555222 1 P/S Pump Reservoir Bracket
15306009 1 Connector
19303244 1 Instruction Sheet
